51.2H LiFePo4 batería de litio iorn 100ah 5kwh batería de litio para almacenamiento de energía en el hogar

Inicio Almacenamiento de energía 51.2H LiFePo4 Lithium iorn
  • Escribe:

    Off-Grid


Característica:
Buen rendimiento a altas temperaturas
Tecnología segura de fosfato de hierro y litio
Alta densidad de energía y eficiencia de conversión.
Vida útil: 2000 tiempos de ciclo
Respetuoso con el medio ambiente, sin metales pesados
Completo con sistema de gestión de batería incorporado
Puede utilizar cargadores solares y de CA para este sistema
Baja tasa de autodescarga
Fácil instalación, puede instalarse en un armario estándar o montarse en la pared
Protección automática incorporada para condiciones de sobrecarga, sobredescarga & sobretemperatura
Alta densidad de energía 120-130kwh / kg, incluso alta tasa de descarga, mientras se mantiene una alta capacidad de energía.
Mayor flexibilidad: el diseño modular permite la implementación
Buena descarga de alta velocidad y excelente estabilidad
Diseño de chip inteligente, excelente capacidad de almacenamiento de la batería.

Aplicaciones:

La batería es aplicable para fines industriales, comerciales o residenciales.

Los módulos o unidades de batería se conectan desde Wh hasta Mwh para un sistema de energía renovable

Sistema de almacenamiento de energía

Almacenamiento de energía solar

Alumbrado público solar

Vehículo eléctrico (EV)

Médico

Telecom

Robótica

UPS

Artículo
Especificación
Escribe
Batería de Litio
Voltaje
51,2 V
Capacidad nominal
100Ah (0.2C / 25 ° C) (Mínimo: 98Ah)
Energía
4200wh
Rango de voltaje de funcionamiento
42 V- 58,4 V (típico: 51,2 V)
Voltaje de carga
56,0 V ± 1,0 V
Voltaje de corte de descarga
42 V ± 2,0 V
Corriente de carga
20A
Corriente de carga (máx.)
30A
Corriente continua
50A
Corriente de descarga (máx.)
100A
Meses de autodescarga
≤3,5%

Embalaje

lithium iron battery

Proyectos

lithium iron battery

Productos relacionados
BIPV, 12W, One piece style, Solar roof tile
Photovoltaic building integration is a solar photovoltaic power generation system that is designed, constructed and installed at the same time as the physical building and forms a perfect combination with the building, which is also known as “building material” solar photovoltaic building. It not only has the function of power generation, but also has the function of building components and building materials, and even enhances the aesthetics of the building, forming a perfect unity with the building.
20ft Container solar storage system
